lithium ion battery 40152S-17AH for solar street lamp
Home > Products > Other Solar Lamp > lithium ion battery 40152S-17AH for solar street lamp

lithium ion battery 40152S-17AH for solar street lamp


  • lithium ion battery 40152S-17AH for solar street lamp
  • lithium ion battery 40152S-17AH for solar street lamp
  • lithium ion battery 40152S-17AH for solar street lamp
  • lithium ion battery 40152S-17AH for solar street lamp
  • lithium ion battery 40152S-17AH for solar street lamp

lithium ion battery 40152S-17AH for solar street lamp

    Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,EXW,FCA
    Min. Order: 24 Piece/Pieces
    Delivery Time: 15-25 Days
    Packaging: 8pcs/carton, 24pcs/carton, 32pcs/carton
    Productivity: 150000pcs/month
    Brand: Headway
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: 150000pcs/month
    Certificate: ISO14001,ISO18001,UL1642,RoHS,TS16949,CB
    HS Code: 8507600090
    Port: Shenzhen,Shanghai

Basic Info

Model No.: HW40152S-17Ah

Product Description

Product Description

Headway lithium ion lifepo4 battery 40152S 3.2V 17AH cell for solar street lamp SPECS

Item
Specification
Nominal capacity
17Ah @ 0.2C
Minimum capacity
16.5Ah @ 0.2C
Nominal voltage
3.2V
Max Charging voltage
3.65 ±0.05 V
Discharge ending voltage
2.5 ±0.05 V
Charge current
Standard charge: 0.5C
Max charge: 2C when T≥10 ℃
Max charge: 1C when 10 OC≥T≥0 ℃
Max charge: 0.1C when 0 OC≥T≥-10 ℃
Discharge current
Standard discharge: 1C
Max continuously discharge: 3C
Max instant (30s) discharge: 10C
Recommended charge and discharge cell surface temperature
Charge: 0~45 ℃
Discharge: -20~60 ℃
Maximum allowable charge and discharge cell surface temperature. Charging and discharging at these conditions will
shorten cell cycle life.
Charge: 60 ℃

Discharge: 75 ℃
Humidity range
0~90%RH (noncondensing)
Internal resistance
≤4mOhm (AC Impedance, 1000HZ)
Cell dimension
Height: 168 mm Max
Diameter: 41.0mm Max
Weight
480±5 g
Detailed Images
Application
Packing & Delivery
Our Company
Certifications
Customer Visit
Attention

Don’t immerse the battery in water;

Don’t use and leave the battery near a heat source such as fire or heater;

When charging, use a battery charger specifically for that purpose;

Don’t reverse the positive and negative terminals;

Don’t discard the battery in fire or heater;

Don’t connect the battery to an electrical outlet directly;

Don’t discard the battery in fire or heater;

Don’t connect the positive and negative terminal directly with metal objects;

Don’t transport and store the battery together with metal objects such as necklaces, hairpins;

Don’t directly solder the battery;

Don’t pierce the battery with a nail or other sharp object.

Zhejiang Xinghai Energy Technology Co.,Ltd



Zhejiang Xinghai Energy Technology Co., Ltd. founded in 2003, located in Changxing Zhejiang, specializing in the development and research, manufacturing and sales of cylindrical lithium ion battery.

The main products are Cylindrical Lithium Iron Phosphate batteries, Lithium Nickel Manganese Cobalt batteries and battery packs for all kinds of application fields, include the power field, energy storage field.

Our company independently developed the Lithium Iron Phosphate batteries on the international market and approved by our customers, our products are mainly exported to Europe, East Asia, South Asia, Southeast Asia, North America, Africa.

The battery quality enjoyed and accepted by the international market and consistent by customers, Our company is authenticated with the certifications of ISO9001, ISO14001, TS16949,OHAS18001,UL, and ROHS test report, which was also recognized as the national high-tech enterprise. It independently develops 20 pcs lithium ion battery core technology and has some patents so far. The patent technology is not only for self-use, but also for exporting to Germany, Iran and Israel. And the price of technology shares in a domestic listed company's new energy company.

Our company always upholds the operation philosophy of creating value for customers and provides customers with first-class products or solutions.

Company Info
  • Company Name: Zhejiang Xinghai Energy Technology Co.,Ltd
  • Representative: Xu Yun
  • Product/Service: Lithium Ion Battery , LiFePO4 Battery , 18650 Battery , 22650 Battery , NCM Battery , Lithium ion Battery Pack
  • Capital (Million US $): 100,000,000RMB
  • Year Established: 2003
  • Total Annual Sales Volume (Million US $): US$10 Million - US$50 Million
  • Export Percentage: 81% - 90%
  • Total Annual Purchase Volume (Million US $): US$1 Million - US$2.5 Million
  • No. of Production Lines: 8
  • No. of R&D Staff: 5 -10 People
  • No. of QC Staff: 5 -10 People
  • OEM Services Provided: yes
  • Factory Size (Sq.meters): 30,000-50,000 square meters
  • Factory Location: No1346, Taihu Road Changxing
  • Contact Person: Mr. Li
  • Tel: 86-572-6128188
